Polymer Concrete Handhole
Built for durability and strength, our Polymer Concrete Handhole features a polymer concrete base reinforced with fiberglass, along with a polymer concrete ring and lid. Designed to meet ANSI 77 TIER 15 and TIER 22 load standards, it provides secure, long-lasting access to underground utilities for telecommunications, electrical, and infrastructure projects.
Features
- Highly resistant to water absorption
- Custom lid design available with client’s logo
- Made in North America
- Compressive strength: 800 kg/cm2
- Non conductive material (dielectric)
- Complies with ANSI SCTE 77 2017 load standards
- Resistance to chemical reagents
- Simulated sunlight exposure
- Water absorption
- Flammability
- Cover impact
- Coefficient of friction
| PRODUCT ID | POLYMER CONCRETE HANDHOLES STANDARD SIZES | TIER | UNIT WEIGHT LBS | PCS BY PALLET | PALLETS BY TRUCK | TL QTY | TL WEIGHT LBS |
|---|---|---|---|---|---|---|---|
| TCQ-12"X12"X12" | POLYMER CONCRETE HANDHOLE 12"X12"X12" | T15 | 54 | 33 | 24 | 792 | 43,728 |
| TCQ-13"x24"x18" | POLYMER CONCRETE HANDHOLE 13"x24"x18" | T22 | 131 | 14 | 24 | 336 | 44,976 |
| TCQ-17"x30"x18 | POLYMER CONCRETE HANDHOLE 17"x30"x18" | T22 | 202 | 8 | 24 | 192 | 39,744 |
| TCQ-17"X30"x24" | POLYMER CONCRETE HANDHOLE 17"X30"x24" | T22 | 230 | 6 | 24 | 144 | 34,080 |
| TCQ-24"x36"x18" | POLYMER CONCRETE HANDHOLE 24"x36"x18" | T22 | 375 | 6 | 19 | 114 | 43,510 |
| TCQ-24"X36"x24" | POLYMER CONCRETE HANDHOLE 24"X36"x24" | T22 | 402 | 6 | 18 | 108 | 44,136 |
| TCQ-24"X36"X30" | POLYMER CONCRETE HANDHOLE 24"X36"X30" | T22 | 398 | 4 | 24 | 96 | 39,168 |
| TCQ-24"X36"X36" | POLYMER CONCRETE HANDHOLE 24"X36"X36" | T22 | 437 | 4 | 24 | 96 | 42,912 |
| TCQ-30"X48"X24" | POLYMER CONCRETE HANDHOLE 30"X48"X24" | T22 | 543 | 4 | 18 | 72 | 39,816 |
| TCQ-30"X48"X36" | POLYMER CONCRETE HANDHOLE 30"X48"X36" | T22 | 726 | 3 | 20 | 60 | 44,360 |
| TCQ-30"X60"X36" | POLYMER CONCRETE HANDHOLE 30"X60"X36" | T22 | 876 | 2 | 18 | 36 | 32,256 |
| TCQ-36"X60"X36" | POLYMER CONCRETE HANDHOLE 36"X60"X36" | T22 | 980 | 2 | 18 | 36 | 36,000 |
| TCQ-36"X60"X48" | POLYMER CONCRETE HANDHOLE 36"X60"X48" | T22 | 1,120 | 3 | 12 | 36 | 40,800 |
| TCQ-48"X48"x48" | POLYMER CONCRETE HANDHOLE 48"X48"x48" | T22 | 1,326 | 1 | 22 | 22 | 30,052 |
| PCS= Peaces/Units | |||||||
| TL= Truck Load | |||||||
| QTY= Quantity |
